Receptacle with Filter Holder

Various types of plug-type components used in communication networks, test equipment, LAN, CATV, FTTH

1

Accord with YD/T1272, GR468 standard;

2

In line with ROHS standard, the metal shell is made of SUS304 stainless steel, suitable for optical communication industry, good welding performance;

3

Good reliability and stability;

4

Mold field :SM, MM;Can ensure that the ceramic insert end face physical index and optical performance index can be customized according to the customer's requirements of various types of size and Angle, according to customer requirements to meet Wiggle standard

3D index: spherical radius 7-12mm, fiber height: -80~0nm, vertex deviation: 0~50nm
Detaching force: >70N
Drawing force: 1~3N
4 direction tests < 0.5db
Repeatability test (500 times) : < 0.3db
It can meet high temperature and humidity: 85℃ 85%RH 1000Hr
High reflection: RL > 45dB
Low insertion loss: IL≤ 0.30db
Durability:: ≥500 times
Temperature range: -40℃-+85℃

Filter Holder Specification:
